Network Parameters
| Model No. : | XVT-42UL |
| Port number : | 4 × 100Mbps PoE ports, 2 ×100Mbps Uplink gigabit RJ45 port |
| Port type : | RJ45 port, full duplex, MDI/MDI-X adaptive |
| Standard : | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab |
| Forwarding : | Store-and-forward switching |
| Working mode : | Standard mode (default), Extend mode, Isolation mode, PoE watchdog mode |
| Ports for long-distance transmission : | Ports 3 & 4 |
| MAC address table : | 2 K |
| Switching capacity : | 4.8 Gbps |
| Packet forwarding rate : | 33.5712 Mpps |
| Internal cache : | 1.0 Mbits |
PoE Power Supply
| PoE Port | : Ports 1 to 4 Support IEEE802.3af(15.4w)/at(30w) Power Supply |
| PoE standard | : IEEE802.3af (Output Power 15.4w)/at(30w) |
| PoE Port Features | : Each port 15.4W (IEEE802.3af)/at(30w) |
| Max. port Power Port | : 60 W Ports 2 to 4: 30 W |
| Core Of Cable | : 1/2+,3/6-(4/5+,7/8- Can custom made) |
| Total Power | : 65/96W |
Environmental Condition
| Working Temperature | : 35’C-75’C |
| Storage Temperature | : 40’C-85’C |
| Operating humidity | : 5-95%RH,noncondensing |
Electromagnetic Radiation
FCC Class A, CE
Power Supply
External power adapter(input AC100-240V 50/60HZ; output 52V1.8A/52V2.3Al
